Survey plats and property maps, 1897 to the present day.

Maps Documents Critter Cam Stories The Anthony Collection

Eight sheets covering a hundred years of survey, from the federal townsite plat of 1897 through to the modern subdivision. Click any sheet to view it large.

Plat of the Townsite of CornwallThe federal townsite survey. It shows the Alamosa River, the Government and State Wagon Roads, Burnt Gulch Creek, Spring Creek and Quartzite Mountain, with section corners, bearings and parcel acreages.
Accepted by the General Land Office, 10 September 1897 ยท 311.86 acres
Retracement plat, survey note sheetCarries the note explaining the whole chain. It records a boundary retracement of the resurvey of the Town of Cornwall made in October 1895 by W. H. Cochran, US Deputy Mineral Surveyor, filed under Reception No. 22052 in Map Book 2 at Page 45. Street names on this sheet include Deer, Pagosa and Alamosa.
Retracement of the 1895 Cochran resurvey
Retracement plat, sheet 1Lot and block detail with the Clerk and Recorder's certificate for the State of Colorado, County of Rio Grande.
Retracement of the 1895 Cochran resurvey
Retracement plat, sheet 3Lot and block detail.
Retracement of the 1895 Cochran resurvey
Retracement plat, sheet 4Lot and block detail.
Retracement of the 1895 Cochran resurvey
Retracement plat, sheet 5Lot and block detail.
Retracement of the 1895 Cochran resurvey
Jasper master platThe modern subdivision plat, with the full street grid and lot tables.
1990
Property overview mapA general property reference map for the Jasper area. A PDF version is available below.
Undated

The property overview map is also available as a PDF: download (206 KB).
